• Surface treatment by ion implantation (hardion™)

    Our process enables the hardening of parts,
    it can also significantly improve metal resistance to corrosion,
    decrease friction losses, or tune the hydrophilicity of glass,
    to give only a few benefits



    Read More
  • Optical power:
    up to 75 mW/cm2
    Exposure area:
    up to 300 x 300 mm2
    Irradiance
    inhomogeneity:

    max. 3%
    Collimation
    angle:

    0.8° to 2.6°
    Exposure
    wavelength:

    365 nm *

    * Single-wavelength version optimized for i-line
    exposure. Mixed-wavelength exposure system
    available in option.

    Products specifications may evolve.
    Visit our website to get up-to-date information.
    Contact us to obtain application-specific advices.




    UV-LED exposure system
    for photolithography

     UV-LED technology is an attractive alternative to traditional arc lamp illumination. The benefits of UV-LEDs are manyfold and significant for photolithography. They operate with consistent emission for very long lifetimes, leading to low maintenance costs. UV-LED lamps are instant-start, and thus do not need several minutes to warm-up and stabilize.

    READ MORE





  • Optics and Machine Vision solutions

    From image processing algorithms to optical installations,
    idonus provides partial or full machine vision solutions.



    READ MORE

  • Shadow Mask Aligner

    with Double Image Microscope

    Designed to accurately align masks with substrates for a wide range of application such as:

    Shadow Masking

    UV-light Masking

    Nanoimprinting

    Bonding Alignment

    and more...

    READ MORE

  • HF Vapor Phase Etcher

    • Sticking free MEMS release
    • Structure thinning
    • Dicing fee release of structures on SOI substrates
    • Etch-rate adjustable from 0 to about 30 um/h
    • Single side SiO2 etching (back-side protected during process)



    READ MORE

idonus is a microtechnology company specialized in the design and manufacturing of specialty equipment aimed for the microengineering industry.

Our core competences are:

  • MEMS equipment (MicroElectroMechanical Systems)
  • Ion Implantation
  • Machine vision and Optical solutions
  • Photovoltaic equipment
  • Engineering services & prototype or small series manufacturing

Our headquarter is located at the Innoparc in Hauterive, Neuchâtel, Switzerland.
